XC 315 Series | 5%RH Dry Cabinets
XC 315 | 330L Dry Cabinet
The Dr.Storage XC 315 Dry Cabinet maintains an internal environment of <5%RH. It is specially designed to store and protect moisture sensitive devices (MSD) from humidity related damage and complies with the IPC/Jedec J-STD-033 standards.
The XC 315 eliminates the oxidation of stored parts and is particularly useful for storing SMT components, component reels, high tech manufacturing devices, precision metal parts, miniature devices, pharmaceutical substance, biotic specimens, battery, crystal, IC package module, optical lens or scientific instruments.
All XC Series Dry Cabinets are plug and play, feature a rugged air tight design and are available in six different sizes. Each cabinet come standard with an anti-static package, adjustable shelves, wheels, locking doors, decimal digital display and a countdown calibration reminder.
Cabinet Specs:
External Size(in): W17.71 X D17.71 X H41.14
Internal Size(in): W17.63 X D16.61 X H34.25
External Size(mm): W450 X D450 X H1045
Internal Size(mm): W448 X D422 X H870
Capacity: 164L
Power Consumption: Ave. 55W/h, Max. 150W
Cabinet Color: Black
Additional Features
Precision CP03 Hygrometer
Simultaneously display temperature & humidity values.
Measurement range:
1-99%RH, 0-50℃
Display Precision: ±3%RH, ±1℃
Designed for measuring in low humidity environment.
Reliable De-Humidifyer
PPS material: 230°C heat tolerance to avoid any deforming or melting of dehumidifiers.
Modular design for easy maintenance & painless upgrade.
Silent, drip less, frostless operation.
Storage Bins
Inside Bin: Store and retrieve important items quickly to shorten the door opening time. (*Optional)
Outside Bin: Ideal for work sheet & quality instructions for better QA management. (*Optional)
Maximum loading of bin: 5Kgs
Adjustable Shelves
Shelves can be flexibly installed in any position.
